5OZ Multilayer Printed Circuit Board
Multilayer Printed Circuit Board multilayer pcb multi circuit boards prototype circuit board
Multilayer Printed Circuit Board
Max layers: 32layer (≥20 layer needs to review)
Max finish panel size: 740* 500 MM(>600 MM needs to review)
Min finish panel size: 5 * 5mm
PCB material: PI +FR4,FR4, Rogers
PCB thickness: 0.2~4.0mm(＜0.2 mm,＞4 mm needs to review)
PCB copper thickness: H~5oz
Bow and twist: 0.075%
Min. hole size: 0.15mm(＜0.15 mm needs to review)
HDI Min drill hole: 0.08-0.10MM
PCB track/gap: 3mil(0.075mm)
PCB outline: Routing/V-CUT/Punching
PCB solder mask: Green, Red, Blue, White, Black, Yellow and as your request
PCB silkscreen: White, Black and as your request
PCB surface: HASL lead free,Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger
Application: Communications, Industry/comsumer Electronic.
Lead time: Fastest 24H for 2L and 4L
| PCB Layer | 1-32L |
| PCB surface | HASL lead free,Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger |
| PCB material | PI +FR4,FR4, Rogers |
| PCB thickness | 0.2~4.0mm |
| Min. hole size | 0.15mm |
| PCB track/gap: | 3mil(0.075mm) |
| PCB outline | Routing/V-CUT/Punching |
| PCB solder mask | Green, Red, Blue, White, Black, Yellow and as your request |
| PCB silkscreen | White, Black and as your request |
| Application | Commnication, Industry/comsumer Electronic |
| Lead time | Fastest 24H for 2L and 4L |
FAQ:
1. What service can you provide?
PCB Manufacture,PCB Assembly,Rapid Prototype
2. How fast is your lead time?
Fastest 24H for 2L and 4L, 3WDs for HDI board.
3. How to get quick quotation?
Please provide gerber file and details of the board(including layer, board thickness, copper thickness, surface treatment, solder mask and silkscreen color, special request if any, demand quantity, etc)
sample:
| PCB Layer | 2L |
| PCB surface | LF-HASL |
| PCB material | FR4, TG170 |
| Copper thickness | 1/1oz finished |
| PCB solder mask | Double side,green |
| PCB silkscreen | Double side,White |
| Quantity | 15pcs,15 working day |
4.What payment terms do you have?
Wire Transfer(T/T)
